One Stop Micro Switch Solution

Subminiature Waterproof Plunger Micro Switch IP67

SPDT micro switch featuring waterproof capabilities
Micro contact gap and tiny action travel, control the circuit quickly and accurately
Compact structure and lightweight design
High sealing performance, ideal for environments where exposure to moisture, dust, and other contaminants is prevalent

Product Series: IP67 Micro Switch KW5
Application: car door locks, pet feeder, ice maker

Subminiature Waterproof Plunger Micro Switch IP67

SPDT micro switch featuring waterproof capabilities
Micro contact gap and tiny action travel, control the circuit quickly and accurately
Compact structure and lightweight design
High sealing performance, ideal for environments where exposure to moisture, dust, and other contaminants is prevalent

Product Series: IP67 Micro Switch KW5
Application: car door locks, pet feeder, ice maker

Subminiature Waterproof Plunger Micro Switch IP67

SPDT micro switch featuring waterproof capabilities
Micro contact gap and tiny action travel, control the circuit quickly and accurately
Compact structure and lightweight design
High sealing performance, ideal for environments where exposure to moisture, dust, and other contaminants is prevalent

Product Series: IP67 Micro Switch KW5
Application: car door locks, pet feeder, ice maker

Subminiature Waterproof Plunger Micro Switch IP67

SPDT micro switch featuring waterproof capabilities
Micro contact gap and tiny action travel, control the circuit quickly and accurately
Compact structure and lightweight design
High sealing performance, ideal for environments where exposure to moisture, dust, and other contaminants is prevalent

Product Series: IP67 Micro Switch KW5
Application: car door locks, pet feeder, ice maker

PRODUCT DETAIL

Chinakel KEL-H Waterproof Micro Switch Feature

Rated Load	0.1A 125/250V AC; 3A 12V DC
Temperature	40T85
Operating Force	≤150gf（regular）
Circuit	SPDT/SPST NO/SPST NC
Contact Resistance	≤500mΩ
Insulation Resistance	≥100MΩ（DC500V）
Withstand Voltage	100V AC（50～60Hz)/1Min
Protection Level	IP67(wiring)
Electrical Life	≥100,000 cycles
Mechanical Life	≥500,000cycles
